We are one of the leading machinery suppliers in India for FULLY AUTOMATIC PAPER CONE MAKING MACHINERY. We are involved in cone manufacturing industry from year 2011. We started our business with semi automatic machinery, which requires many skilled labours and sunlight for drying the cones. As our business was dependable on labour and sunlight, we were facing many problems in supplying the right quality of cones on right time. That made us to get into a fully automatic paper cone making machine.
This machine does the following process:
1. Jumbo reel feeding with one touch.
2. Online printing, both inside and outside.
3. Paper tension and aligner.
4. Inside and outside grinder for smooth egde pasting.
5. Online double side glueing.
6. Pnematic pattern cutting.
7. Robotic pattern feeding to winding.
8. Winding of paper to make a required specification of cones with base cutting & nose cutting.
9. Counting the cones and auto feed to driyer.
• Automatic paper cone making machine Speed - 30-55pcs/min
• Applicable paper - 220 to 350 gsm
• Applicable glue – CONETECH Cold mix glue
• Operator – 1 Person/shift
• Labour – 1 person/shift
The wet cones which are manufactured moves into the driyer automatically one by one through the conveyors connected, and come out of driyer one by one in a time span of 20 minutes in the temperature of 80 to 100 degree Celcious. Such driyed cones and stacked together and feed automatically to the cone finishing machine. The driyer is powered by electricity. We also have an option of coal or diesel powered driyers.
This machine does the following process :
1.Paper cone auto feeding one by one.
2.Base furnishing.
3.Notching.
4.Nose waxing.
5.Nosing.
6.Velvetting.
7.Gruving.
8.Counting & stacking to the required quantity for packing.
• Automatic paper cone finishing machine Speed - 30-55pcs/min
• Labour – 1 person/shift
Our entire machine is powered by Servo motors, which reduces the mechanical works in the machinery.
Thus our machinery becomes very easier for maintainance.
Generic Name : Cone / Cheese Collapsing Strength Tester
Product # : DCT – A1
Industry Usage : Spinning Paper Cone
FEATURES :
Measure the collapsing strength of cones and cheeses.
Table top model ; Working under pneumatic method.
Automatic operation with pneumatic control ensures accurate results.
Dual push button system ensures operator safety and ergonomic comfort.
Auto-stop and auto-return upon completion of test.
Stable electronics ; State-of-art microcomputer controlled soild state control circuity.
Specially made cone / cheese jaws suitable for standard cones / cheeses.
Unit of measurement : kgf and kg/cm
Direct result ( Force / Load) are read-out form LED display.
TECHNICAL DATA :
Measuring range : 25 to 300 kgf / 0.5 to 6 kg/cm 2
Accurac : 1 kgf / 0.01 kg/cm 2
Cone jaws size : Any of the two jaws (5 , 57 , 4 , 3 , 30 and cheeses)
Operating air pressure : 6.00 + or - g0.04 bar
Display : Seven segment numerical LED display
Required Air Pressure : 6.0 to 7.0 bar dries and filtered air
Power supply : Single phase 220vAC @ 50Hz; Consumption : 25 watts
Weight : 20 kg
SCOPE OF SUPPLY
1. Main Unit – 1 No.
2. Accessories : Cone jaws – 2 Nos. and Mains cord – 1 No.
3. Spares : Glass fuse (1 Amps) – 3 No’s.
Optional Supply : Cone jaws (As per customer requirements)
PRE – REQUISITES FOR INSTALLATION
Suitable working table, Properly earthed and stabilized single phase
220vAC @ 50 Hz ported at 5 Amps supply socket, Laboratory standard compressed air supply at 7.0 bar,
Test cones and Suitably qualifies operator.
This machine is capable to press and bale the scrap paper. The scraps can be easily stored and transported.
• EB Required - 15Hp.380v/50HZ/3Phase.
• Machine Parameters:
• EB Required – 60Hp 380v/50HZ/ 3 Phase (With electrical driyer).
• EB Required – 28Hp 380v/50HZ/ 3 Phase (With coal or diesel driyer).
• Production Capacity – 40000 cones to 50000 cones in a day (24 hrs).
• PLC controlled with touch screen.
• Air compressor required – 15Hp . 50Cfm, 8 Bar pressure.
• Weight of Machinery – 15.6 Tons.
• Size of Machinery – 40feet * 20 feet*10feet(Length*Width*height).
• Building space required- 5000 Square feet.
• Total Operator – 1 Person/shift
• Total Labour – 2 person/shift
We supply the following specification of paper for manufacturing paper cones.
• Kraft.
• Semi Kraft.
• Gsm 220 - 350
• Any Required Sizes.
